Edwards Signaling 102 Tone Module - Manual

P/N 3100702 ISSUE 1 © 2003
Installation Instructions for Triliptical TM
Stackable Status Indicator Tone Modules
Description
The Edwards Triliptical Stackable Status Indicator is a unique au-
dible-visual signaling device that can contain up to 5 light modules
and either a single or multiple tone module in a single "stack."
All components of the Triliptical Stackable Status Indicator are UL
and cUL listed subassemblies. The units, when assembled, are UL
and cUL listed for indoor and outdoor applications. The enclo-
sures are NEMA 3R, 4X, and IP65 rated. See Table 1 for specifica-
tions.
The indicator bases are available in three models. Two models
feature a shorter base that is used when a lower profile is desired;
the other model features a larger base with a terminal block de-
signed to function as a junction box for use with an optional horn
assembly.
Installation must be in accordance with local codes.
1. Mount the base using one of the following methods:
NOTE: For NEMA 3R, 4X, and outdoor applications, it is
recommended that the unit be conduit mounted vertically
facing up.
a. Cat. No. 102TBS Pull field wiring through conduit entrance
hole. Install base on 3/4" (19 mm) conduit (not supplied).
2. Connect field wiring.
a. Cat. No. 102TBS Connect field wiring to the terminal block
as shown in Figure 1.
b. Connect additional field wiring to the terminal block
mounted on the signal assembly as shown in Figure 2.
NOTE: The tone module may be wired to sound independently or in
conjunction with a light signal.
(1) To sound tone independently, connect to separate
hot lead.
(2) To sound tone with a particular light, connect tone
module hot terminal to selected light terminal on Cat.
102TBS terminal block.
3. If using the multi-tone module, Cat. No. 102SIGMT, set the
selected tone. See Table 2 and Figure 3.
NOTE: For further installation details, see the instructions supplied
with the lens modules, P/N 3100700, with the base, P/N
3100669, or with the light sources, P/N 3100701.
Catalog No. Voltage Current (A)
102SIGST-G1 24V DC 0.05
102SIGST-N5 120V AC 0.07
102SIGMT-G1 24V DC 0.05
102SIGMT-N5 120V AC 0.07
Table 1. Specifications
WARNING
To prevent electrical shock, do not connect power
until instructed to do so.
Switch Settings*
Tone 1 2 3
Stutter beep OFF OFF OFF
Hi / Lo ON OFF OFF
3 Pulse Horn OFF ON OFF
Continuous OFF OFF ON
Yeow ON ON OFF
Fast Whoop ON OFF ON
Rapid Siren OFF ON ON
Beep ON ON ON
*ON is in the "UP" position (see Figure 3).
Installation
Table 2. Switch Settings
Cheshire, CT 06410 203-699-3300 (Ph)
203-699-3365 (Cust. Serv. Fax)
203-699-3078 (Tech. Serv. Fax)
