6 ESL 500N Series
Specifications
Voltage for standard 6/12 V operation
(6 to 20 VDC), polarity
sensitive for standard 12/24 V
operation (8.5 - 33 VDC),
polarity sensitive
Maximum ripple pk-pk (6/12/24V) 10% (V pk-pk)
Typical average standby current 70 uA
Typical alarm current (6/12/24V) up to 60mA maximum if not
limited by control panel
Aux. relay contacts 1A @ 30 VDC; Form C
Alarm contacts 500mA @ 36 VDC (resistive)
Photoelectric sensitivity 2.0% + 1.08 - 1.02
Operating termperature 32 °F to 100 °F (0 °C to 37 °C)
Operating humidity range 0 to 95% non-condensing
RFI immunity 20V/m minimum; 0-1000MHz
Color white head and base
1036525 Rev. B 09/02
12345 SW Leveton Drive
Tualatin, OR 97062
www.interlogixsecurity.com
www.sentrol.com
Phone: 503-692-4052
USA & Canada: 800-547-2556
Technical Service: 800-648-7424
FaxBack: 800-483-2495
© 2002 GE Interlogix, Inc.
2266 Second Street North
North St. Paul, MN 55109
www.interlogixsecurity.com
www.itii.com
Phone: 651-777-2690
USA & Canada: 800-777-5485
Technical Service: 800-648-7424
Field wiring size 12-24 AWG (16 - 22 AWG
recommended)
Electrical boxes Fits standard single gang and
3 1/2” and 4” round ceiling
electrical boxes
Detector packaging 10 detectors per carton
Heat detector specifications rate-of-rise: 15°F/min and
>105 °F (8.3 °C/min and
>40.6 °C) fixed threshold:
135 °F (57.2 °C)
UL 2-wire compatibility identifiers: S09A, S10A, S11A
Drift compensation adjustment 1.0%/ft. maximum
Detector head dimensions 5.5” (14.0cm) diameter;
2” (5.0cm) deep
Mounting dimensions 5.25” (13.3cm) diameter;
0.3” (0.8cm) deep
Reset time 1 second minimum
Listings: CSFM,MEA
State of Maryland
C-UL US UL 268, ULC-S531
GE Interlogix
Product Ordering
521NBXT
Series Listing Features
Wiring New Style
Model Description Alarm Reverse
Current (mA) Polarity (mA)
521NB 2-wire, photoelectric, 6 - 33 VDC, S09A/S10A 20 -
521NBXT 2-wire, photoelectric, 6 - 33 VDC, fixed temp and rate-of-rise heat, S09A/S10A 20 -
521NCRXT 2-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, aux. relay, S11A 25 -
521NCSXT 2-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, temporal 3 sounder, 30 13
S10A
521NCSRXT 2-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, aux. relay, 35 13
temporal 3 sounder, S11A
541NB 4-wire, photoelectric, 6 - 33 VDC 20 -
541NBXT 4-wire, photoelectric, 6 - 33 VDC, fixed temp and rate-of-rise heat 20 -
541NCSRXT 4-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, aux. relay, 35 13
temporal 3 sounder
541NCSXTE 4-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, built-in end-of-line 45 28
relay, temporal 3 sounder
541NCSRH 4-wire, photoelectric, 8.5-33 VDC, isolated fixed temp and rate-of-rise heat, aux. relay, 35 13
temporal 3 sounder, non-latching LED with auto reset
541NCRXT 4-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, aux. relay 25 -
541NCXTE 4-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, built-in 25 -
end-of-line relay
541NCSXT 4-wire, photoelectric, 8.5-33 VDC, fixed temp and rate-of-rise heat, temporal 3 sounder 30 13
B 6 - 33V operation
C 8.5 - 33V operation
E End-of-Line relay
H Isolated rate-of-rise and fixed temp sensors
N New style
R Auxiliary relay
S 85dBa sounder
XT Multi criteria algorithm, rate-of-rise and fixed temp. sensors
