Ordering Information/Electrical Specifications
PART NUMBER
1
CONTACT
2
LOAD RATING
SWITCHING VOLTAGE
SWITCHING CURRENT
CONTACT
NOMINAL SENSE RANGE
3
BREAK RANGE
TERMINAL
CONFIG.
AC/DC
MAXIMUM, AC/DC
MAXIMUM, AC/DC
RESISTANCE
Max. Min.
NOMINAL
TYPE
381-CT
N.O.
2.5VA/2.5W
[email protected] [email protected]
[email protected] [email protected]
0.5 Ohms
0.75"(1.9cm) 0.375"(1.0cm)
1.2"(3.0cm)
#6 Screw
381-DT
5
N.O.
150VA/NA
1.25A
4
@120V NA
NA
0.75"(1.9cm) 0.375"(1.0cm)
1.2"(3.0cm)
#6 Screw
Warning— Each electrical rating is an individual maximum and cannot be exceeded!
1
The part numbers 381 and 383 are the same in all respects except the conduit connection, 381 is left and 383 is right.
2
Configuration with actuator away from the switch
3
Proximity of ferrous materials usually reduces sense range — typically by 50%. The shape and type of material cause a wide diversity of effects.
Testing is required to determine actual sense range for specific applications.
4
Can withstand inrush surge up to 4 amps. Voltage drop is 1.5V. Minimum Switch Current 30mA.
5
Do not exceed 10 switches in series.
General Specifications
Enclosure
Coated Aluminum
Temperature Range
-40
°
F to 180
°
F (-40
°
C to 80
°
C)
Environmental
Hermetically Sealed Contact Switch
Encapsulated in Polyurethane
NEMA Rating
1, 2, 5
Protection Class
IP 64
Response Time
1 msec (5.4VA); 10 msec (150VA)
Life Cycles
100,000 Under Full Load;
Up to 200,000,000 Under Dry Circuit
Conduit Connection
1/2" Threaded NPT
UL/CSA
All Models
Perpendicular
Actuation
Door
Actuation
Parallel Actuation
Best
Best
Not Recommended
Pivot Actuation
Good
Figure 2
Mounting Configurations
The parallel actuation can result in on/off/on signal if the actuator passes by the
switch rather than coming to rest in proximity to it. This is NOT a recommended
configuration for safety interlock applications.
LR89176
Accessories
PART NUMBER
TAMPER PROOF SCREWS & SCREWDRIVER
1953
#6 x 3/4"L Tampruf
Roundhead Screw
1954
#8 x 1-1/2"L Tampruf Roundhead Screw
1955
Tampruf
®
Screwdriver
1956
Tampruf
®
1/4" Drive Bit for #6 and #8 Screws
4. For best protection against operator defeat, mount with non-removable screws,
bolts or nuts (see Accessories).
5. When mounting a metal switch to an ungrounded machine, connect the ground lead
to one of the switch mounting screws.
triac
output
File E 122942
