Edwards Signaling 116EXMLED Series User Manual
Page 4
Table 1. 116 Series AdaptaBeacons
Catalog
Electrical
Conduit
Flash
LED
Description
Number
Ratings
Size
Rate
Replacement
Housing Less
116EXMLED*-Y6
120 - 240V 50/60 Hz, .215A
N/A
ADJUSTABLE
N/A
Mounting Module
125-250V DC, .176A
Ceiling/Wall
116EX-C
N/A
3/4" NPT
N/A
N/A
Mounting Module
Pendant
116EX-P
N/A
3/4" NPT
N/A
N/A
Mounting Module
Stanchion
116EX-S
N/A
1 1/4" NPT
N/A
N/A
Mounting Module
Wall Bracket
116EX-B
N/A
N/A
N/A
N/A
Mounting Elbow
*Letter in this position denotes color of the lens: A - amber, B - blue, W - clear, G - green, R - red
P/N 3101456 ISSUE 1
Table 2. Ratings
Operating Temperature
Ambient
Supply Wire
Class I, Div. 2
Class I, Div. 1 & 2
Class II & III, Div. 1
Class II & III, Div. 2
Temp.
Temp. Marking
Groups A, B
Groups C, D
Groups E, F, G
Group F, G
40°C
75°C
T4 (135
°
C)
T6 (85
°
C)
T4A (120
°
C)
T4A (120
°
C)
55°C
90°C
T3C (160
°
C)
T6 (85
°
C)
T4 (135
°
C)
T4 (135
°
C)
65°C
105°C
T3C (160
°
C)
T6 (85
°
C)
T4 (135
°
C)
T4 (135
°
C)
Contacting Edwards:
Phone:
(800) 336-4206
E-Mail:
Website:
http://www.edwardssignaling.com
Table 3. Flash Mode Selection
S4
S3
S2
S1
DESCRIPTION
PATTERN
OFF OFF OFF OFF
Steady
Steady On
OFF OFF OFF
ON
Multiburst 1
7 Bursts - Delay - Repeat
OFF OFF ON
OFF
Multiburst 2
5 Bursts - Delay - Repeat
OFF OFF ON
ON
Multiburst 3
10 Bursts - 3 Bursts - Repeat
OFF
ON OFF OFF
Multiburst 4
8 Bursts - delay w/ slight illumination - Repeat
OFF
ON OFF
ON
Flash 1
65 FPM 10% Duty Cycle
OFF
ON
ON
OFF
Flash 2
65 FPM 25% Duty Clyle
OFF
ON
ON
ON
Flash 3
65 FPM 50% Duty Clyle
ON
OFF OFF OFF
Flash 4
65 FPM 75% Duty Clyle
ON
OFF OFF
ON
Flash 5
80 FPM 10% Duty Clyle
ON
OFF ON
OFF
Flash 6
80 FPM 25% Duty Clyle
ON
OFF ON
ON
Flash 7
80 FPM 50% Duty Clyle
ON
ON OFF OFF
Flash 8
80 FPM 75% Duty Clyle
ON
ON OFF
ON
Ramper
Ramps up and then ramps down
