Edwards Signaling 215-F6 GuardSwitch - Manual (Page 4)

www.ge-security.com/industrial
12345 SW Leveton Drive
Tualatin, OR 97062
Phone: 800-247-9447
Fax: 503-691-7563
GE Security
Industrial
©2004 GE Security Industrial. GE Security Industrial reserves the right to change specifications without notice.
I-3919-0404 12946 Rev C
PART CONTACT 1 LOAD RATING SWITCH CURRENT VOLTAGE RANGE CONTACT SENSE RANGE 2 BREAK RANGE BREAK AT LEAD LENGTH
NUMBER CONFIG. AC/DC Max. (AC/DC) (AC/DC) RESISTANCE NOMINAL NOMINAL FAILURE Max. NOMINAL
215-F6Y-06J N.O. 12W/VA 0.5A 24 ± 4V 0.5 Ohms 0.7"(1.8cm) 1.8"(4.6cm) 2.5"(6.8cm) 6'(1.8m)
215-F6Y-12J N.O. 12W/VA 0.5A 24
±
4V 0.5 Ohms 0.7"(1.8cm) 1.8"(4.6cm) 2.5"(6.8cm) 12'(3.6m)
215-F6Y-16J N.O. 12W/VA 0.5A 24
±
4V 0.5 Ohms 0.7"(1.8cm) 1.8"4.6cm) 2.5"(6.8cm) 16'(4.8m)
115Y Actuator Only Included with all switches unless otherwise noted.
Warning— Each electrical rating is an individual maximum and cannot be exceeded!
1 Configuration with actuator away from the switch
2 Proximity of ferrous materials usually reduces sense range — typically by 50%. The shape and type of material cause a wide diversity of effects. Testing is required to determine actual sense range for specific applications.
Ordering/Electrical Specifications
Accessories
PART NUMBER TAMPER PROOF SCREWS & SCREWDRIVER
1954 #8 x 1-1/2"L Tampruf Roundhead Screw
1955 Tampruf ® Screwdriver
1956 Tampruf ® 1/4" Drive Bit for #6 and #8 Screws
