To perform the functional test with CO test spray:
1. Press and hold down the test/hush button until the red
LED illuminates (approximately 2 seconds).
2. Wait for the buzzer test to complete.
The red LED flashes every 4 seconds and the green LED
flashes every 16 seconds indicating that the device is in
fast CO test mode.
3. Direct the UL approved CO testing agent spray to the
sensor port of the 250-CO. See Figure 7.
The unit immediately goes into an alarm mode upon
sensing the applied gas. The sounder and red LED
activate in a temporal-four pattern with a five second
pause in between. The alarm relay activates.
If the level of applied CO gas is still significant, the device
continues to alarm in this pattern.
4. Exit the fast test mode by either:
• Pressing the test/hush button until the green LED
illuminates (approximately 2 seconds)
• Waiting five minutes, until the unit automatically exits
out of the fast CO test mode
To perform the alarm relay test:
1. Press the test/hush button for approximately 5 seconds to
start a test cycle.
2. Wait for the Buzzer test to complete.
3. Verify that the panel reacts correctly to the alarm relay
activation.
4. Exit the alarm relay test mode by either:
• Pressing the test/hush button until the green LED
illuminates (approximately 2 seconds)
• Waiting five minutes, until the unit automatically exits
out of the fast CO test mode
Specifications
Input voltage 12 or 24 VDC supplied by control panel or
resettable auxiliary power supply
Current consumption
Normal
Alarm
20 mA
40 mA (75 mA in test)
Alarm relay
Type
UL
rating
150 mA at 33 VDC
Form C
Zone
Common trouble relay
Type
UL rating
150 mA at 33 VDC
Normally opened held closed with power
applied
Common
Sounder 85 dB
Compatible control panel Listed to ANSI/UL 985 or 864 standards
Compatible electrical box 2-1/2 in. (64 mm) deep single-gang
Wire size 14 to 22 AWG (0.25 to 2.0 mm²)
Dimensions (W × L × D)
Detector
Adapter
plate
3.1 Ч 4.6 Ч 1.3 in. (7.8 Ч 11.7 Ч 3.2 cm)
4.5 Ч 6.5 Ч 0.2 in. (11.4 Ч 16.5 Ч 0.5 cm)
Weight
Detector
Adapter
plate
4.7 oz. (133 g)
1.6 oz (46 g)
Color White
Operating environment
Temperature
Relative
humidity
32 to 104°F (0 to 40°C)
0 to 90%, noncondensing
Regulatory information
Manufacturer
Edwards, A Division of UTC Fire & Security
Americas Corporation, Inc.
8985 Town Center Parkway, Bradenton, FL
34202, USA
Year of
manufacture The first two digits of the product serial number
(located on the product identification label) are
the year of manufacture.
UL rating Regulated 12 DC, Regulated 24 DC
North American
standards ANSI/UL 2075
This detector has been evaluated to the CO
alarm sensitivity limits of ANSI/UL 2034.
Environmental
class Indoor
Contact information
For contact information, see www.utcfireandsecurity.com.
