Page 34
33
must be closed. If the configuration of the unit
has changed e.g. thermocouple type, the software
will read and reconfigure itself to match the
instrument.
Operation
Alarms-
A small box located to the left of the alarm box
indicates alarm status. An L inside the box indicates a low
alarm limit and an H indicates a high alarm limit. A grey box
with no letter indicates an inactive alarm.
5
6
7
8
9
10
1
2
3
4
REAR VIEW
5
3 2
7
2 3
9 PIN CONN
25 PIN CONN
Tx
Rx Com
Computer
side
RS232
Rx
Tx Com
