20
Analog Output
The analog output option translates the indicators’ display
reading to a proportional analog output signal. There are two
versions of the analog output option, either 0-10VDC or 4-
20ma. Both voltage and current outputs are scaleable within
their ranges and are similarly programmed. Note that the
analog output is active only in the display mode. As soon as
the
indicator is put in the program mode, indicated by a P in
the lower right hand corner of the display, the output goes to
its zero output value. The display reading can be scaled from
-999 to +9999, which enables the user to use only a portion of
the full scale if necessary.
Analog Output Setup
Example1:
Program the indicator to output 4.0 ma at 32.0
°
F and 20.0 ma at 500
°
F...
STEP 1. Press the PGM button. PGM will appear on the
display. The
°
F/
°
C LED will change to P (for ‘Program
Mode).
STEP 2.
Press the Arrow key until ALOG appears on the
display. Open the ALOG Menu for programming by pressing
the ENT key.
STEP 3. A LOW or HIGH will appear. Pressing the Arrow
key repeatedly will cause LOW and HIGH to alternate on the
display. With LOW on the display, select LOW by pressing
the ENT key. The digits 0000 will appear with the left most
