Model CX-IR
3.1 Operator Interface
The operating interface is menu-driven via the two magnetic program switches located under the target marks
of the sensor housing. The two switches are referred to as PGM1 and PGM2. The menu list consists of three
menu items that include sub-menus:
Normal Operation
Concentration reading is displayed once every 10 seconds.
Calibration Mode
AutoZero
AutoSpan
Program Mode
View Sensor Status
CX-IR ##.##
Serial Number
Range ###
Autospan Level ##
Modbus ID ##
Last Cal ## Days
Sensor Life ###%
Temperature ##C
Set Gas Type
Set Autospan Level
Set Gas Factor
Set Modbus ID
Bump Test
Restore Defaults
CX-IR Instruction Manual Rev. 1.2 Page 12 of 34
