EMO-500
Operation and Programming Manual
5
Quick Start Guide
As with any precision-engineered device, always operate the EMO-500 in accordance with the
manufacturer’s instructions.
Connect to Flow Transmitters
You will connect three wires from each of the two sensors to the back of the EMO-500 (see samples next
page):

Insert the two red wires (electrical power) to the two +18 volt terminals

Insert the two white (signal) wires to the input terminals

Insert the two black (ground) wires to the ground terminals
Use a screwdriver to secure.
Color of wires may vary.
Connect the higher flow side to flow meter A as the Ratio calculation is A/B.
Caution
Notice
Notice
