EMO-500
Operation and Programming Manual
13
External Resets and Controls (Definitions)
Reset All
This reset is the most powerful on the EMO-500. It resets:

Ratio A/B

Job Vol A, Job Vol B and Job Vol A+B

Warning and Alarm Limits

Limits 3 and 4

Grand Totals

Analog Outputs to start point
Scroll Display
This input scrolls through all of the 11 screens available. It also allows access to the Quick Programming
functions, which are highlighted in red on the upper keypad line. (See page 14 for more details on Quick
Programming).
Reset Job B - resets OFF-RATIO WARNING/ALARM (LIMIT 1 and 2)
This input resets the Job B totalizer. It also resets the A/B RATIO to the IDEAL setting, which
simultaneously resets the WARNING and ALARM LIMITS.
Reset Job A - resets OFF-RATIO WARNING/ALARM (LIMIT 1 and 2)
This resets the Job A total. It also resets the A/B RATIO to the IDEAL setting, which simultaneously resets
the WARNING and ALARM LIMITS.
Simultaneously pressing and holding RESET JOB A and RESET JOB B on the keyboard, or through the
back-panel connections, actuates HOLD TOTAL.
Enable Full Programming
Enables the F2 through F6 keys to perform the programming functions shown in red on the banner strip
above the keypad.
F3, F4, and F5 serve as Job Resets in the Job Totals screen when the Enable Programming switch is OFF.
