EMO-500
Operation and Programming Manual
29
The value you enter ignores the decimal point position.
For Example:
In Ratio Mode (06)

If Ideal Ratio = 5.00, variable value = 500

If Ideal Ratio = 10.00, variable value = 1000
In Flow Mode (00-02)

If Flow Rate = 80.0 cc/m, variable value = 800

If Flow Rate = 200.0 cc/m, variable value = 2000

If Flow Rate = 5.25 GPM, variable value = 525
In Flow Mode (03-05)

If Total Flow = 10.00 Gal, variable value = 1000
11. Analog Rule (Default 06)
The analog rule allows you to set the analog output to follow any of the variables listed below. Enter a
number as the Analog Rule.
00 - Flow A 06 - Ratio
01 - Flow B 07 - Ratio Feedback Mode
02 - Flow A+B 08 - Ratio w/Reset
03 - Total A 09 - Ratio Feedback w/Reset
04 - Total B 10 - A - B Job Total
05 - Total A+B 11 - A - B Flow Rate
These variables are used in the computations as numbers in Engineering Units (ccpm, gals, ozs., etc.).
This means that any Decimal Points are dropped. For example, 113.7ccpm is 1137 for computation
purposes.
