Model AS Conductivity Cells
www.WaterAnalytics.net 978-749-9949 Toll free - 855-747-7623 (855-pHProbe)
Cell Constants 0.01, 0.1, 0.5, 1.0, 10 and 50
Thread size 3/4” NPT
Temperature Compensation* Automatic, 0 to 105 0 C
Cable Length 20 ft. (6.1 m)
Insertion Length Variable. See table below
Wetted Materials 316 stainless steel, polypropylene,
Epoxy and EPDM. Compression
fitting: CPVC or 316 stainless steel.
Safety Feature Shoulder on cells provides
an integral safety stop
Temperature and Pressure 3 metres (10 ft.) coaxial, terminated
with a spade lug for active electrode,
other wires tinned
316 stainless steel, polypropylene,
epoxy and EP
Temperature and Pressure
Type Max pres. (psi) Max temp. ( 0 C)
P 50 60
100 50
150 20
S 200 105
Cell Constant Selection
Constant Code
0.01 001
0.1 01
0.5 05
1.0 1
10 10
Temperature Compensa-
tion Device Selection
Description Code
PT1000 RTD 1
3 kΩ ohm NTC 2
Type Selection
Description Code
Cell with PVC fitting P
Cell with 316 stainless steel fitting S
Cell for Ball Valve Assembly HT
MS Series of probes
MHMSC, 24 inch (610 mm) long 1” CPVC pipe w/ cable clamp
MS-HTC, 3/4” socket-weld CPVC ball valve assembly
AM3422, AM3444 and AM3455 316 SS body conductivity sensors
Technical Data
Dimensions
Ordering Information
Related Products
