Aquametrix ES-1 Series Toroidal Conductivity Sensors - Manual (Page 2)

Model ES-1 Series Electrodeless Conductivity Sensors
Dimensions
Order Information
www.WaterAnalytics.net 978-749-9949 Toll free - 855-747-7623 (855-pHProbe)
ES-1-A Polypropylene body with convertible style, 3/4”NPT thread fitting
C42-ES-XXX Interconnect extension cable- specify length
ES-5 series of 4-20 mA direct output toroidal probe
Related Products
Wetted Materials
Talc reinforced blocked-copolymer Polypropylene, UV
protected
Measuring Range
0-200 μS to 0-2 S; Exact ranges and measurement ac-
curacy are determined by the instruments, and values
below 500 μS are subject to increased error percent-
ages due to zero offset and noise.
Temperature Compensation
Pt 1000 RTD, Class B
Operating Temperature Range
-10 to 105°C (sensor only, not mounting hardware)
Pressure/Temperature Limits
105 psi at 105°C
Maximum Flow Rate
10 ft (3 m)/sec
Sensor Cable
3 shielded pairs plus 2 isolated shields with enhanced
PVC jacket rated to 105°C continuous; 20 ft (6 m)
long, stripped and tinned instrument connection ends,
matched to color code of GLI Models E33, E53, E63
and all other instruments that work with GLI Model
3700 electrodeless sensors
Process Connection
3/4” MNPT at cable end of sensor
Technical Data
