Model AM-TBR Turbidimeter
www.WaterAnalytics.net 978-749-9949 Toll free - 855-747-7623 (855-pHProbe)
Specifications
Range 0 to 1000 NTU or 0 to 100
Measurement Principle Nephelometry
Light Source White Light or IR (850 nm LED)
Measurement Principle Nephelometry
Accuracy <40 NTU: 2% of reading or ±0.02
>40 NTU: 5% of reading
Resolution 10 -3
Response Time Adjustable from 5 to 500 seconds
Analog Output 4-20 mA isolated, 600 Ω drive
Digital Output Bidirectional RS485 / Modbus, Online Interface
Alarms high/low/system alarms
Operating Temperature 1 to 50 0 C (34 to 122 0 F)
Input Pressure 1 - 200 psi (regulated at 15 psi)
Flow Rate 0.1 to 1 liter/min (.026 to gal/min)
Wetted Materials Nylon, borosiicate glass, polypropylene, 316 SS
Power Supply 100-240 VAC, 47-63 Hz, 80 VA
Display Custom backlit LCD
Enclosure NEMA 4X, IP 66
Environmental Conditions Not recommended for outdoor use. Altitude up to 2000 m. Up to 95% RH
Insulation Rating Double Insulated, Pollution Degree 2, Over-voltage Category II
Certifications UL 6101B-1, CSA 22.2 No. 1010.1-92, CE, ISO 7027, USEPA
Shipping Weight 2.5 kg (5.5 lbs)
Light Source
1 White light source (EPA 180.1)
2 IR source (ISO 7027)
Range
100 0-100 NTU
1000 0-1000 NTU
Options
C Ultrasonic Cleaning
Accessories
TCAL-100 Primary Calibration Kit, Low
Range (0.02, 10 and 100 NTU)
TCAL-1000 Primary Calibration Kit, Full
Range (0.01, 10 and 1000 NTU)
Order Information
Dimensions
