Model P65C/R65C pH or ORP Probes with 4-20 mA Output

www.WaterAnalytics.net

978-749-9949

Toll free - 855-747-7623 (855-pHProbe)

Technical Data

Related Products

Measuring Range

pH

0 to 14 pH (Consult factory for applications

below 2 or above 12).

ORP

-500 to +500 mV or

0 mV to +1000 mV, field selectable

Flow Rate

10 ft./sec maximum (3 metres/sec)

Flow should be as low as possible in low

conductivity water and in solutions with

high suspended solids

Wetted Materials

CPVC, kynar, glass, titanium palladium al-

loy and EPDM (platinum for ORP probe);

opt. viton and ceramic

Transmission Distance

Dependant upon transmission distance

and supply voltage

Sensitivity

pH

0.001 pH

ORP

0.1 mV

Stability

pH

0.03 pH per day, non-cumulative

ORP

2 mV per day, non-cumulative

Temperature Copensation

Automatic

-5 to 95°C (23 to 203°F)

Pressure Limit

100 psig at 65°C maximum

Temperature Limits

CPVC

-5 to 95°C (23 to 203°F)

The temperature limit of probes in flow-

through applications is limited by pressure

and by the pipe fitting material.

Probe Cable

5 Conductor plus shield, 15 ft. (4.6m) long

CABLES & ACCESORIES

JB1

NEMA 4X junction box

C42-1-XXX

Interconnect cable; dressed both ends - specify length

C35-17(K)

Salt Bridge Kit for P/R65C-4/-6/-7 probes, package of 3

AM60-9765K

Salt Bridge Kit, all P/R65C-8 probes, package of 3

P60-HTC

Hot Tap Ball Valve assembly

CALIBRATION SOLUTIONS

A35-13

pH 4 Buffer, 500 mL.

A35-14

pH 7 Buffer, 500 mL

A35-24

pH 10 Buffer, 500 mL

A35-40

ORP Buffer, 200 mV, 500 mL

A35-41

ORP Buffer, 600 mV, 500 mL

Ordering Information

P/R65C-8

Flow-through or submersion applications; body threaded 1-1/2” both ends (P-pH; R-ORP)

P/R65C-6

“Easy-in Easy out” variable insertion depth, 1-1/4” fitting (P-pH; R-ORP)

P/R65C-7

For use with Hot-Tap hardware (P-pH; R-ORP)

P65C-8-F

Flat-Face pH probe

P65C-8-A

Antimony pH probe

R65C-8-G

ORP probe with Gold electrode

Dimensions

18”

1.25” NPT

Compression

Fitting
