Aposonic A-H2A8D2 - Manual (Page 111)

- 111 -
Backup 1 USB 2.0 port for USB 2.0 disk drives, DVD+RW,
DVD+R, DVD-R , card readers, HDD, etc.
Internal DVD models: DVD+RW, DVD+R, DVD-R
Alarm Set/unset 1 contact or TTL/CMOS signal, polarity selectable
Panic 1 contact or TTL/CMOS signal, polarity selectable
Input 16 contact or TTL/CMOS signal, polarity selectable
Output 2 Normally Open, 2 Normally Closed relay output
Buzzer Yes
Triggered by Sensor input, Video loss, & Motion
Event log Yes
Network Ethernet 1 RJ-45 10/100BaseT Ethernet connector
Web Remote setup, monitoring, backup, alarm notification,
&
remote software upgrade
1 I.E./Firefox for multiple DVRs
DDNS Free DDNS server
E-mail Alarm notification to stationary or mobile devices
FTP Alarm video/audio file storage
Video 1/4/9/16 split-window & SEQ mode for I.E. and HEM
Dynamic electronics maps for HEM
Audio Bidirectional
Protocol TCP/IP, HTTP, PPPoE, DHCP, DDNS, FTP, TSP
Remote users Up to 8 users simultaneously
Bandwidth TCP/IP type dynamic sliding window control
Remote stations PC, mobile phone, PDA, and/or tablet PC
With free iPhone/iPad/Android software app.
Control /
GPS /
POS
Remote
Controller 1 remote controller
Optional extension cable
RS-232 1 D-type female connector for PTZ, keyboard, POS,
or GPS
RS-485 2-pin for keyboard or PTZ control
Setup Local On screen setup via keypad, remote, mouse , and/or
RS-485 keyboard controller
Remote Setup & upload via Windows application software
Multi-lingual Yes
Reliability System recovery Auto power on after power loss recovery
Watch Dog Timer Yes
Timer
Built-in real time clock
Security Multi-level password (4 levels, up to 18 accounts)
protection with authentication key for remote access
Weights &
Measures Dimension
Weight 430(W) x 350(D) x 66(H)mm
4.0 KG (without HDD)
Power Source +12 VDC
Consumption 100W Max. w/ 5 HDDs, 50W Max. w/ 2 HDDs
Operating Temperature 0
o
C ~ +40
o
C
