Using Cable P/N 59044-10-SPN from the Office Power Kit
*: These items are part of the SP80 Office Power Kit P/N 94336 (option).
Using Cable P/N 95715 from the Field Power Kit
This cable is primarily designed to power an RTK base from
an external battery (see Completing Base Radio Setup With
External UHF Antenna on page 50). But it can also be used
in the office to connect to the AC/DC power block.
*: This item is part of the SP80 Office Power Kit P/N 94336 (option).
**: This item is part of the SP80 Field Power Kit P/N 94335 (option)
Power
Cord
AC/DC
Power Block Power/Data Cable *
SP80
SAE/Jack-f
Adapter
Cable *
To AC
Outlet
Power/Data
Connector
Power
Cord
AC/DC
Power Block
Power Cable **
SP80
SAE/Jack-f
Adapter
Cable *
To AC
Outlet
Power/Data
Connector
