Recording/Downloading GNSS Raw Data
Data Recording
Flowchart
NOTE: Dotted diamond shapes hold questions solved by the
firmware, solid ones those answered by the user.
Step-by-Step
Procedure
The SP80 can at your request record GNSS raw data on the
selected storage medium. Raw data recording may take place
in the background while making a real-time RTK survey. The
name of the file being recorded may be read on the Memory/
SD card screen (see Memory/SD Card on page 19).
The SP80 is designed to let you easily control both the
beginning and end of data recording.
While data recording takes place, the SP80 will also allow you
to define beginnings and ends of static occupations (periods
of time during which the receiver is kept stationary).
This will translate into adequate tags inserted into the raw
data file at their exact times of occurrence. When post-
processing the file, the office software will be able to process
these tags as well.
SD-Card
present?
No No
(Internal Memory
Will Be Used)
Yes Yes
(Internal
Memory)
Raw Data Recording
now in progress...
No Raw Data Recording
in progress...
(No)
Select
Storage
Medium
Used
(SD Card)
Start
Data
Recording?
(Yes)
Stop
Occupation?
Start
Occupation?
(No)
(No)
(Yes)
(Yes)
(No) Start
Occupation?
(Yes)
Raw Data Recording
now stopped...
(No)
(Yes)
Stop
Data
Recording?
General Status
Screen
Occupation
in progress?
Raw Data Recording
now in progress...
General Status
Screen
