Seed Hawk Manual
Tool Bar
Page 18
3.7 45 SERIES TOOLBAR 10”
10” (254 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Number of
Sections
*Folded Width
ft (m)
Folded Height
ft (m)
30’ (9.15 m)
36
3
14’ 8” (4.47 m)
13’ 0” (3.96 m)
40’ (12.19 m)
48
5
14’ 8” (4.47 m)
14’ 7” (4.46 m)
50’ (15.24 m)
60
5
14’ 8” (4.47 m)
14’ 7” (4.46 m)
60’ (18.29 m)
72
5
14’ 8” (4.47 m)
16 ’8” (5.08 m)
3.8 45 SERIES TOOLBAR 12”
12” (305 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of Seed
Rows
Number of
Sections
*Folded Width
ft (m)
Folded Height
ft (m)
30’ (9.15 m)
30
3
14’ 8” (4.47 m)
13’ 0” (3.96 m)
40’ (12.19 m)
40
5
14’ 8” (4.47 m)
14’ 7” (4.46 m)
50’ (15.24 m)
50
5
14’ 8” (4.47 m)
14’ 7” (4.46 m)
60’ (18.29 m)
60
5
14’ 8” (4.47 m)
16 ’8” (5.08 m)
3.9 45 SERIES TOOLBAR 15”
15” (381 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Number of
Sections
*Folded Width
ft (m)
Folded Height
ft (m)
30’ (9.15 m)
24
3
14’ 8” (4.47 m)
13’ 0” (3.96 m)
40’ (12.19 m)
32
5
14’ 8” (4.47 m)
14’ 7” (4.46 m)
50’ (15.24 m)
40
5
14’ 8” (4.47 m)
14’ 7” (4.46 m)
60’ (18.29 m)
78
5
14’ 8” (4.47 m)
16 ’8” (5.08 m)
*Folded width and height can be reduced by removing wing tires.
