Seed Hawk Manual
Tool Bar
Page 17
3.4 XL SERIES TOOLBAR 10"
10” (254 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Number of
Sections
*Folded Width
ft (m)
*Folded Height
ft (m)
65’0” (19.81 m)
78
5
28’4” (8.64 m)
17’10” (5.45 m)
71’8” (21.85 m)
86
7
28’4” (8.64 m)
17’10” (5.45 m)
80’0” (24.38 m)
96
7
28’4” (8.64 m)
17’10” (5.45 m)
3.5 XL SERIES TOOLBAR 12"
12” (305 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Number of
Sections
*Folded Width
ft (m)
*Folded Height
ft (m)
66’0” (20.12 m)
66
5
28’4” (8.64 m)
17’10” (5.45 m)
72’0” (21.95 m)
72
7
28’4” (8.64 m)
17’10” (5.45 m)
80’0” (24.38 m)
80
7
28’4” (8.64 m)
17’10” (5.45 m)
84’0” (25.60 M)
84
7
28’8” (8.74 m)
17’11” (5.46 m)
3.6 XL SERIES TOOLBAR 15"
15” (381 mm) Row Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Number of
Sections
*Folded Width
ft (m)
*Folded Height
ft (m)
65’0” (20.12 m)
52
5
28’4” (8.64 m)
17’10” (5.45 m)
72’6” (21.95 m)
58
7
28’4” (8.64 m)
17’10” (5.45 m)
80’0” (24.38 m)
64
7
28’4” (8.64 m)
17’10” (5.45 m)
85’0” (25.60 M)
68
7
28’8” (8.74 m)
17’11” (5.46 m)
