Seed Hawk Manual Tool Bar Page 15
3.1.4 Tire Torque
Tire Size Description Torque N·m (lb-ft)
11 L 15 SL (8 ply) Wing Castor (Front and Rear) 203 (150)
11 L 15 FI (12 ply) Main Frame Castor (Front) 203 (150)
19.0 / 45 x 17 Main Frame Castor (Front) 203 (150)
500 / 45 x 22.5 Rear Axle Tire 271 (200)
30.5 L 32 SAT (Single) Rear Axle Tire 475 (350)
30.5 L 32 SAT (Inner Dual) Rear Axle Tire
475 (350)
30.5 L 32 SAT (Outer Dual) Rear Axle Tire
475 (350)
3.2 TIRE PRESSURE
Use the following chart to check and adjust, if necessary, tire pressure.
Tire Size Description PSI Rating
480 x 400 x 8 Packer Tire 14-16 PSI
11 L 15 SL (8 ply) Wing Castor (Front and Rear) 36 PSI
11 L 15 FI (12 ply) Main Frame Castor (Front) 90 PSI
19.0 / 45 x 17 Front Main Frame Castor 58 PSI
500 / 45 x 22.5 Rear Axle Tire 52 PSI
30.5 L 32 SAT (Single) Rear Axle Tire 26 PSI
30.5 L 32 SAT (Inner Dual) Rear Axle Tire 26 PSI
30.5 L 32 SAT (Outer Dual) Rear Axle Tire 16 PSI
NOTE: Proper inflation of tire pressure contributes to longer tire life and proper
flotation for field operations. Tire inflation pressures listed are recommended initial
settings. Some soil conditions and operating environments may dictate deviation
(on Pneumatic Packer Tires Only) from the recommended settings. Contact Seed
Hawk

for additional information and advice if needed.
NOTE: If you do change your tire pressure, ensure that your opener is correctly
placing your seed at the depth you require.
