Seca 685 - Manual (Page 44)

44
9. Technical data
Dimensions scale
width:
910 mm / 35.8 ins
height: 1100
+10
mm / 43.3
+0.4
ins
depth: 965 mm / 38 ins
Dimensions weighing platform
width:
800 mm / 31.5 ins
height: 46
+10
mm / 1.8
+0.4
ins
depth: 850 mm / 33.5 ins
Weight approx. 59 kg
Temperature range +10 °C to +40 °C
Calibration as per Directive
2009/23/EC approved for medical use, Class III
Medical product as per Directive
93/42/EEC Class I
Colour white/black
Maximum load
Weighing range 1
200 kg
Weighing range 2 300 kg
Maximum load for folding seat
150 kg
Minimum load
Weighing range 1
2 kg
Weighing range 2 4 kg
Graduations
Weighing range 1
100 g
Weighing range 2 200 g
Accuracy at first calibration
Weighing range 1:
to 50 kg:
± 50 g
50 kg to 200 kg :± 100 g
Weighing range 2:
0 to100 kg:
±100 g
100 kg to 300 kg: ± 200 g
Power supply mains unit
