32
4. Setting up and aligning the scale
– Place the scale on a level surface.
– Undo the locknuts using the four foot
screws (1).
– Align the scale by undoing the foot
screws. The air bubble in the spirit level
must be right in the centre of the
circle (2).
– Then re-tighten the locknuts (3).
– Ensure that only the feet of the scale are
in contact with the floor. The scale may
not be in contact at any other point.
Important!
The alignment of the base of the scale must be checked and corrected if neces-
sary every time the location of the scale is changed.
Moving the scales
To move the scales to a different location,
1.
Take hold of the left side element and
tip the scales carefully over until the
scales are on the castors.
2. With the scales in this position, push
to the desired location.
1.
2.
3.
Libelle
spirit level
