Block (4) OUTPUT TYPE:
The electrical output from the INFRADUCER is classified according to whether or not it is linear or according to the
thermocouple type as follows:
L:
Linear 4-20 mA output.
U Any non-standard output (must be specified in writing). Output typically is proportional to
infrared radiation curves.
When this type of output is supplied, the appropriate table showing the output as a function of temperature of the source will be
provided.
Block (5)
FOCUS DISTANCE:
If standard factory focusing is appropriate, code “S” is inserted in Block 5 . If non-standard focusing is required code “U” is
inserted in Block number 5, and the desired focus distance is written on specification label.
Block (6)
OUTPUT RESPONSE TIME:
Specify desired, initial, factory set, output response time by inserting the proper code letter in box number 6. Output response
time is field adjustable should factory setting need to be changed after delivery.
Block (7)
PROTECTIVE JACKET:
Designate the type of protective jacket supplied by code “I”, for protective jacket without cooling or code “J”, for protective
jacket with cooling. If no protective jacket is supplied. Letter “O” appears in this block.
Block (8)
AIR PURGE ASSEMBLY:
Letter “L” in this block represents an Air Purge Assembly. If no Air Purge Assembly is supplied, letter “O” appears in this
block.
Block (9)
AIMING FLANGE:
Letter "P" in this block represents an Adjustable Aiming Flange. If no Adjustable Aiming Flange is supplied letter "O" appears
in this block.
