4.2 HDD INSTALLATION

Caution: When working with electrostatic sensitive devices such as hard disk drive or DVR

unit, make sure you use a static-free workstation. Any electrostatic energy coming in contact

with the hard disk drive or DVR can damage it permanently.

Please install the HDD with the following steps:

1）Open the cover of the DVR and you will see one HDD plate as follow:

2）Connect HDD cables as follow:

3）Secure HDD onto HDD plate as indicated below with the screws provided:

4）Install the HDD plate back into DVR and close cover.

Notice: New installed HDD must be formatted before recording.
