Warning – Hired-Hand Emergency Back-Up and Alarms: Secondary Sensing System User Manual
Page 36
Manual No. 4801- 2997 Rev 7-08
Secondary Sensing System
36 of 40
12.10 Connecting Local Network Connections to the S
3
Warning!
Tape Shield To Prevent Damage!
NOTE:
Harness to connect Local Network and Secondary Sensing system
together are connected & included in the Secondary Sensing System
and 16 Stage Expansion units.
Back-Up
System
