Hired-Hand Emergency Back-Up and Alarms: Secondary Sensing System User Manual
Page 33
Manual No. 4801- 2997 Rev 7-08
Secondary Sensing System
33 of 40
12.7 Connecting an Alarm or Siren to the S
3
Inset A
White
Red
NO
NC
Com
Alarm Out
Siren
Internal
Switch
(Non-alarm)
position
Connect to alarm,
modem, auto-
dialer,etc. as
desired.
White (-)
Red (+12V)
Siren
Secondary Sensing System
Inset A
