Hired-Hand Emergency Back-Up and Alarms: Secondary Sensing System User Manual
Page 28
Manual No. 4801- 2997 Rev 7-08
Secondary Sensing System
28 of 40
12.2 S
3
Circuit Board Layout
HH.Net
3 Amp Slo-Blow Fuse – F1
(for Main Power Supply to S-3)
Control,
Aux 2,
& Aux 1
Jumpers
Battery
Alarm /
Siren
Control,
Aux 2, &
Aux 1
Sensors
Net Term
Jumper
Connection for
Stand-Alone
Option Board
Tunnel
Override
Vent
Override
3 Amp Slow-Blow Fuse – F2
(for Evolution Back-Up Power Supply)
AC Power
Connector
Transformer
Back-Up
System
Local Net
