Hired-Hand Emergency Back-Up and Alarms: Secondary Sensing System User Manual
Page 30
Manual No. 4801- 2997 Rev 7-08
Secondary Sensing System
30 of 40
12.4 Connecting Sensors to the S
3
White/
Shield
Black
Sen 3
Black
White/
Shield
Sen 2
White/
Shield
Black
Sen 1
Inset A
Secondary Sensing System
Inset A
SENSOR
SENSOR
SENSOR
White / Shield
White / Shield
White / Shield
Black
Black
Black
