11.1 Installation
11.2 Unpacking Components
Unpack the system, and check that all components are present. Locate the required tools.
1 Evolution 3000 Back-Up
1 Temperature Sensor
1 Manual
11.3 Installation Instructions
1. Hang Evolution Back-Up with four screws and the plastic mounting brackets included.
2. Make sure all power supplies are disconnected before breaking any wires, or reaching into the
enclosure.
3. Locate the sensor connections. Refer to Wiring Diagrams, Schematics, etc.
4. For the Back-Up, run sensors out to locations inside the house. Be sure that the sensors are in a safe
location, free from any extreme temperature influences (direct sunlight, water, etc.) Use care when
securing sensor wires so that you do not cut the wire. Any short or break in the wire will cause
improper sensor operation.
5. Connect each sensor to its appropriate terminals inside the enclosure. See Section 12.2.
6. Wire the power supply. See Section 12.4.
7. Wire the Back-Up to the EV-3000. See Wiring Diagrams at the back of this manual.
8. Wire the Local Network connection.
9. Connect the PowerTrak to the Overrides. See Diagram in Section 12.3.
10. Close the Back-Up and tighten the two screws in the lid to secure the unit shut.
11.4 Checklist For Setting Up Control of House Temperature
Please read and follow the Installation instructions on the following pages. Refer to the following
checklist as an aid in setting the Evolution Back-Up controller.
1. Physically install the controller, temperature
sensors, and wires leading from the output
stages to cooling and/or heat equipment or to
a control panel.
Refer to Section 12, Wiring Diagrams
2. Verify the Back-Up jumpers on the Stage
Block. Set Heat/Cooling Stage options.
Refer to the Evolution 3000 Owners Manual,
Part Number 4801-5307 and to Section 7 of
this manual,
3. Install power to controller. Refer to Section 12.4.
4. Set High Limit & Low Limit Refer to Section 9, Set Limits.
5. Calibrate Sensors Refer to Section 11, Calibrate Sensors
Tools Required:
Mini Screwdriver
Wire Strippers
Standard Screwdriver
