Powertrak – Hired-Hand Emergency Back-Up and Alarms: Evolution Back-Up User Manual
Page 11
Part No. 4801-5309 rev 10-05
Evolution Back-Up
11 of 16
12.3 Evolution Back-Up Power Trak Override Settings and Wiring
NOTE: If curtain is setup to pull curtain up to open, then reverse wires connected
to 'Open' and 'Close' terminals.
Inset A
Vents Override
Evolution Back-Up Circuit Board
Inset B
PowerTrak
Inset A
Vent Override
To
EV-3000
Cont
Hot
PT
Hot
PT
Open
Vent Override
PowerTrak
AUX
SWITCH
CONTROLLER
AC IN
HO
NEUT.
LOW
E
R
GND
HO
OU
CLOSE
O
PEN
IN
COM
UPPER
Inset B
Com
Open
Close
INLET
MODE
Vent Override
Cool 1
Tunnel Override
Cool 3
Vents & Tunnel Will Wire The Same
Tunnel Override
