Hired-Hand Emergency Back-Up and Alarms: Evolution Back-Up User Manual
Page 12
Part No. 4801-5309 rev 10-05
Evolution Back-Up
12 of 16
12.4 Power Supply Connection
NOTE: Controllers shipped from HHI set to
240V. Set slide switch of power selector to
voltage of power supply connected!
Evolution
Back-up
Cabinet
Evolution 3000 16 Stage
Ex
p
ansion Module
Evolution 3000
Cabinet
INSET A
Ins
e
t A
(AC input
on PCB
171)
External GND
Hot
Neutral
External GND
Hot
Neutral
External GND
Hot
Neutral
External GND
Hot
Neutral
AC
Junct
ion
B
ox
Breaker
B
ox
NOTE:
R
un power cabl
es
including ground from each
cabinet to a common AC
junct
ion box. Do NOT run
AC
power and ground
between cabinets.
IMPORTANT!
Back-up Can Be On A Separate Breaker
From Main Controller For Added
Protection
