Inset a – Hired-Hand Farm Hand Series: Vent Master 16 Stage User Manual
Page 35
Part No. 4801-5098 Farm Hand Vent Master 32
14.9 Connecting the Vent Master to a Series or Parallel Alarm
V FAN IN V FAN OUT
# 1
Inset A
Note: The internal wiring shows the condition of the alarm relay during
normal conditions (no alarm present). During an alarm condition,
the contact positions will be reversed.
Inset A
