Hired-Hand Farm Hand Series: 4 Stage Controller User Manual
Page 22
4801-5058 Rev 8-04
Farm Hand 4 Stage Controller
22 of 30
12. Connecting the 4 Stage to a Series or Parallel Alarm
4 Stage Controller
Inset A
Note: The internal wiring shows the condition of the alarm relay
during normal conditions (no alarm present). During an alarm
condition, the contact positions will be reversed.
Inset A
