Hired-Hand Contactor Control System (CCS): 4, 8, or 12 Stage - Manual (Page 19)

Contactor Control Systems 17
Chart B - Contactors
Part No. Description Application
3011-2308 CNTCTR SP 120VAC coil All 120 Volt Single Pole CCS Models
3011-2378 CNTCTR SP 240VAC coil All 240 Volt Single Pole CCS Models
3011-2444 CNTCTR DP 120VAC coil All 120 Volt Double Pole CCS Models
3011-2469 CNTCTR DP 240VAC coil All 240 Volt Double Pole CCS Models
3011-2470 CNTCTR TP 120VAC coil All 120 Volt Triple Pole CCS Models
3011-2440 CNTCTR TP 240VAC coil All 240 Volt Triple Pole CCS Models
3011-2475 CNTCTR DP 24VAC coil All 24 Volt Double Pole CCS Models
Chart C - Back-up Relay Boards
Part No. Description Application
6404-1175 PCB111 after QA Single All Single Pole CCS with Back-up
6404-1185 PCB115 after QA Double All Double Pole CCS with Back-up
6404-1189 PCB118 after QA Triple All Triple Pole CCS with Back-up
Chart D - Transformers
Part No. Description Application
3008-0051 XFMR115/230V20VCT50/60HZ 12 Single/Double, and 8 Triple 120/240
3008-0052 XFMR120/240 12/24 40va n/fuse 4 and 8 stage120/240 Single & Double
Chart E - Lighting Contactors
Part No. Description Application
3011-2444 CNTCTR DP 120VAC coil All 120 Volt CCS Panels with Lighting
3011-2469 CNTCTR DP 240VAC coil All 240 Volt CCS Panels with Lighting
