Hired-Hand System 1000 Power Vent User Manual
Page 10

System 1000
Power Vent Controller
8
attach contacts to the position marked "NC". If your alarm is a "normally
open" system, use the position marked "NO".
9.
Apply power to the system.
Set points
The unit allows the operator to set the system according to his or her needs. Set
points can be changed as often as desired. The range of these set points are as
follows:
Feature
Minimum
Maximum
High end temperature
High end pressure
Low end temperature
Low end pressure
High pressure alarm
Low pressure alarm
Differential
20
o
F
0 "w.c.
0
o
F
0 "w.c.
.0500 "w.c.
0 "w.c.
.0100 "w.c.
100
o
F
.2000 "w.c.
100
o
F
.2000 "w.c.
.2000 "w.c.
.1000 "w.c.
.1500 "w.c.
Minimum pressure
Timer period
Vent time delay
.0100 "w.c.
1 min
0 sec.
.2000 "w.c.
30 min
300 sec.
Recommended Wire Gauge for LOW VOLTAGE hookup.
Component
HHI Wiring Part No. Recommended Wire
Sensor
1502-2427
18/2 Shielded Cable
Hall Effect Devices
1502-2427
18/2 Shielded Cable
PVR-H
1503-1508
18/3 Cable SJT
