Brocade FastIron WS Hardware Installation Guide - Manual (Page 57)

Brocade FastIron WS Hardware Installation Guide 47
53-1002498-02
Chapter
5
Hardware Specifications
Hardware specifications for FastIron WS models
This chapter contains hardware specifications for the Brocade Communications Systems Inc.
FastIron WS.
Physical dimensions and weight
The following sections list the physical dimensions and weight for the FastIron WS family of
switches and redundant power supplies.
FastIron WS family of switches
The following tables list the physical dimensions and weight for the FastIron WS family of switches.
Redundant power supplies
The following tables list the physical dimensions and weight for the redundant power supplies.
Table 18 lists the physical dimensions and weight of the RPS2-EIF Redudant Power Supply.
TABLE 14 Physical dimensions and weight of the FWS624, FWS624G
Platform Height Width Depth Weight
FWS624, FWS624G 4.34 cm
1.7 in 44 cm
17.32 in 35 cm
13.78 in
•
4.1 kg(9 lbs )
TABLE 15 Physical dimensions and weight of the FWS648, FWS648G
Platform Height Width Depth Weight
FWS648,
FWS648G 4.34 cm
1.7 in 44 cm
17.32 in 35 cm
13.78 in
•
4.5 kg (10.8 lbs)
TABLE 16 Physical dimensions and weight of the FWS624-PoE, FWS624G-PoE
Platform Height Width Depth Weight
FWS624-PoE,
FWS624G-PoE 4.34 cm
1.7 in 44 cm
17.32 in 35 cm
13.78 in
•
4.9 kg (10.8 lbs)
TABLE 17 Physical dimensions and weight of the FWS648-PoE, FWS648G-PoE
Platform Height Width Depth Weight
FWS648-PoE,
FWS648G-PoE 4.34 cm
1.7 in 44 cm
17.32 in 35 cm
13.78 in
•
5.3 kg (11.7 lbs)
