Cable length summary (Continued) TABLE 28
Cable Type Connector Type Core
Diameter(microns)
Modal
Bandwidth(MHz*km) or
Wavelength (nm) Range
(meters)
1000Base-LX Multi-mode
Fiber (MMF) LC connector for
SFP module 62.5 500 2 - 550
MMF 50 400 2 - 550
MMF 50 500 2 - 550
SMF 9 1300 nm 2 - 10000
1000Base-SX MMF LC connector for
SFP module 62.5/125 200 .5 - 275
MMF 62.5/125 500 .5 - 550
MMF 50/125 900 .5 - 595
MMF 50/125 1500 .5 - 740
MMF 50/125 2000 .5 - 860
1000Base-T Copper RJ-45 jack for
standard
unshielded
twisted pair (UTP
or Category 5) n/a n/a up to 100
meters
100Base-FX MMF LC connector for
SFP module 62.5 500 up to 2000 (2
km)
100Base-FX-
IR MMF SC 62.5 125 2 km (1.24
miles)
100Base-FX-
LR SMF SC 9 125 20 km (12.43
miles)
10GBase-CX4 Infiniband
4x copper
XAUI connector n/a n/a up to 15
10G SFP+ TWNX SFP n/a n/a 1, 3, and 5
Power cords
All devices ship with US-compatible power cords unless otherwise specified at the time of order.
United Kingdom- and European-compatible power cords are also available.
