Brocade VDX 8770-4 Four-Post Flush and Recessed Mount Intake Air Duct Rack Kit Installation Procedure

Publication Number: 53-1003114-02

NOTE

Screws, clip nuts, and retainer nuts to secure the switch to the rack are provided in the hardware accessory kit
that accompanies the switch.

FIGURE 17

Brocade VDX 8770-4 with the Intake Air Duct Kit installed in the rack in a recessed configuration

NOTE

For rails with round holes, use the clip nuts on the rails for securing the 10-32 screws. For rails with square
holes, use the retainer nuts. Refer to

Figure 10 on page 15

and

Figure 11 on page 16

Screw locations for mounting switch
