USER’S GUIDE
Battery Management System
89
Event list format
The evntlist.htm page defines the following for each event:
• Code : The event’s unique event code.
• Description : The text used for the event.
• Severity : The event’s default severity level.
• Configuration : The hexadecimal code that defines the actions to
occur for the event and provides a link to the event mask that you use
to configure the event.
Event mask settings
From the evntlist.htm page, to reconfigure actions for an event:
1. Click the link (the current hexadecimal code) for the event.
2. Enter a new hexadecimal code as an event mask to reconfigure the
bits that control the actions for the event.
3. Click Apply .
The bits are numbered 0 to 23, from left to right.
See Event mask settings .
Bit 5 and bits 14 through 23 are unused. Make sure these
bits are always set to 0.
