G1-1
IM 01W02E01-01EN
PART-G. SPECIFICATIONS
G1. Standard Specifications
G1.1 Communication Interface Specifications
Item
Field Network
Specifications
Field Wireless Backbone Specifications *1
Communication
Interface
Standard IEEE802.15.4 IEEE802.11a/b/g *2 100BASE-TX 100BASE-FX
Frequency 2400–2483.5MHz b/g: 2400-2483.5MHz
a: 5150-5850MHz
–
Raw data rate 250kbps 1~54Mbps 100Mbps 100Mbps
Radio Security AES128bit WPA2-PSK –
RF Transmitter
Power
Max 12dBm *3 Max 18dBm *3 –
Connector N type N type RJ-45 SC connector
[ single pole × 2 ] *4
Cable Type coaxial coaxial Category 5 Multimode fiber
(50/125μm or
62.5/125μm)
Antenna +2dBi – –
Remote Antenna +2dBi, +6dBi, +9dBi +2dBi, +6dBi, +9dBi –
Maximum length 500m *5 b/g: 500m *5
a: 200m *5
100m 2000m
Port 1 port Max 2 port 1 port 1 port
Protection – – Surge –
Communication
Protocol
Field Wireless ISA100.11a –
Management,
configuration, etc.
– IEEE1588PTP v2 *6 , Proprietary *7
*1: In outdoor wiring to Field Network or 100BASE-FX of Field Wireless Backbone, use optical fiber cables with a nonmetallic
tension member, combining with YFGW610
*2: This product requires a wireless LAN access point for connection with YFGW410 in the wireless LAN in field wireless
backbone.
*3: This is the maximum radio output at N-type connector for antenna connection. Radio output power depends on the region
and the antenna type.
*4: 2-pole SC connector cannot be used due to the conduit hole size limitation. SC connector should use Short Boot type.
*5: The maximum length needs perfect conditions without an obstruction for radio wave transmission, using a standard
antenna (2dBi). The maximum length changes with the environmental conditions and installation situations of a site.
*6: Installation of these multiple product and YFGW410 in one field wireless subnet requires direct connection or the
connection via IEEE1588PTP basis products.
*7: TCP based custom protocol used for communication between this product and YFGW410.
n Communication interface specifications for YFGW510 configuration
Interface Item External Specifications Remarks
Infrared communication
Communication protocol IrDA-SIR Ver. 1.2
Wavelength 870 nm
Maximum transmission speed 9600 bps
Maximum transmission
distance
30 cm
Number of ports 1
Purpose Initial configuration of YFGW510
