IM 01C50T03-01E 3-3
3. OPERATION
ADJ
J:CAL SENSOR1 J05:SNSR1 CLR
J07:IN TRIM MODE
J10:SNSR1 ZERO
J20:SNSR1 GAIN
J30:SNSR1 SERIAL
J60:SELF CHECK
K:CAL SENSOR2 K05:SNSR2 CAL CLR
K10:SNSR2 ZERO
K20:SNSR2 GAIN
K30:SNSR2 SERIAL
K60:SELF CHECK
L:CAL OUTPUT L05:OUT CLR
L10:OUTPUT MODE
L20:OUT ZERO
L30:OUT GAIN
L60:SELF CHECK
M:SET METER M10:PROCESS DISP
M20:%/mA DISP
M40:BAR GRAPH
M50:DISP UPDATE
M55:Err-NO DISP
M60:SELF CHECK
O:MEMO O10:MEMO1
O20:MEMO2
O30:DESCRIPTOR
O40:DATE
O60:SELF CHECK
P:RECORDS P05:LOG CLEAR
P10:PV MIN LOG
P11:PV MAX LOG
P12:SV MIN LOG
P13:SV MAX LOG
P14:TV MIN LOG
P15:TV MAX LOG
P16:4V MIN LOG
P17:4V MAX LOG
P18:TERM MIN LOG
P19:TERM MAX LOG
P20:ERR LOG 1
P21:ERR LOG 2
P22:ERR LOG 3
P23:ERR LOG 4
P24:ERR LOG CLR
P30:OPERATE TIME
P31:POWER CHECK
P40:BCC ERROR %
P60:SELF CHECK
SET
C:SET TAG C10:TAG NO.
C60:SELF CHECK
D:SET SENSOR1 D10:SENSOR1 TYPE
D20:SENSOR1 WIRE
D40:SENSOR1
D41:SNSR1 UNIT
D60:SELF CHECK
E:SET SENSOR2 E10:SENSOR2 TYPE
E20:SENSOR2 WIRE
E40:SENSOR2 TEMP
E41:SNSR2 UNIT
E60:SELF CHECK
F:SET OUTPUT F10:LRV
F20:URV
F30:AUTO LRV
F35:AUTO URV
F40:BURN OUT
F41:BURN OUT VAL
F50:TX FAILURE
F60:SELF CHECK
G:FORCED OUT G10:OUTPUT MODE
G20:OUTPUT VALUE
G60:SELF CHECK
H:SET MODE
H10:REVERSE OUT
H20:SNSR BACKUP
H21:RETURN SNSR1
H30:UPLOAD SELCT
H40:WRITE PROTCT
H50:WARNING ENBL
H60:SELF CHECK
I:INFORMATION I10:PV LRL
I11:PV URL
I12:PV MIN SPAN
I20:SNSR1 LSL
I21:SNSR1 USL
I30:SNSR2 LSL
I31:SNSR2 USL
I40:TERM LSL
I41:TERM USL
I59:WARNING
I60:SELF CHECK
HOME
A:VARIABLE A10:PV
A11:mA of RANGE
A20:SV
A30:TV
A40:4V
A50: TERM
B:SET VAR CON. B05:SET DIFF
B10:PV is
B11:PV UNIT
B12:PV DAMPING
B13:PV DMP POINT
B20:SV is
B21:SV UNIT
B22:SV DAMPING
B30:TV is
B31:TV UNIT
B32:TV DAMPING
B40:4V is
B41:4V UNIT
B42:4V DAMPING
B51:TERM UNIT
B60:SELF CHECK
Menu tree for YTA320
ADJ
J:CAL SENSOR1 J05:SNSR1 CLR
J07:IN TRIM MODE
J10:SNSR1 ZERO
J20:SNSR1 GAIN
J30:SNSR1 SERIAL
J60:SELF CHECK
L:CAL OUTPUT L05:OUT CLR
L10:OUTPUT MODE
L20:OUT ZERO
L30:OUT GAIN
L60:SELF CHECK
M:SET METER M10:PROCESS DISP
M20:%/mA DISP
M40:BAR GRAPH
M50:DISP UPDATE
M55:Err-NO DISP
M60:SELF CHECK
O:MEMO O10:MEMO1
O20:MEMO2
O30:DESCRIPTOR
O40:DATE
O60:SELF CHECK
P:RECORDS P05:LOG CLEAR
P10:PV MIN LOG
P11:PV MAX LOG
P12:SV MIN LOG
P13:SV MAX LOG
P14:TV MIN LOG
P15:TV MAX LOG
P16:4V MIN LOG
P17:4V MAX LOG
P18:TERM MIN LOG
P19:TERM MAX LOG
P20:ERR LOG 1
P21:ERR LOG 2
P22:ERR LOG 3
P23:ERR LOG 4
P24:ERR LOG CLR
P30:OPERATE TIME
P31:POWER CHECK
P40:BCC ERROR %
P60:SELF CHECK
SET
C:SET TAG C10:TAG NO.
C60:SELF CHECK
D:SET SENSOR1 D10:SENSOR1 TYPE
D20:SENSOR1 WIRE
D40:SENSOR1
D41:SNSR1 UNIT
D60:SELF CHECK
F:SET OUTPUT F10:LRV
F20:URV
F30:AUTO LRV
F35:AUTO URV
F40:BURN OUT
F41:BURN OUT VAL
F50:TX FAILURE
F60:SELF CHECK
G:FORCED OUT G10:OUTPUT MODE
G20:OUTPUT VALUE
G60:SELF CHECK
H:SET MODE
H10:REVERSE OUT
H30:UPLOAD SELCT
H40:WRITE PROTCT
H50:WARNING ENBL
H60:SELF CHECK
I:INFORMATION I10:PV LRL
I11:PV URL
I12:PV MIN SPAN
I20:SNSR1 LSL
I21:SNSR1 USL
I40:TERM LSL
I41:TERM USL
I59:WARNING
I60:SELF CHECK
Menu tree for YTA110 & YTA310
F0300.EPS
A12:% of RANGE
A60:SELF CHECK
M30:MATRIX DISP
M30:MATRIX DISP
HOME
A:VARIABLE A10:PV
A11:mA of RANGE
A20:SV
A30:TV
A40:4V
A50: TERM
B:SET VAR CON. B10:PV is
B11:PV UNIT
B12:PV DAMPING
B13:PV DMP POINT
B20:SV is
B21:SV UNIT
B22:SV DAMPING
B30:TV is
B31:TV UNIT
B32:TV DAMPING
B40:4V is
B41:4V UNIT
B42:4V DAMPING
B51:TERM UNIT
B60:SELF CHECK
A12:% of RANGE
A60:SELF CHECK
H01:CJC SELECT
H02: CNST CJC TMP
H01:CJC SELECT
H02: CNST CJC TMP
