Wa t l o w S e r i e s S D 6 L i m i t w i t h D e v i c e N e t ■ 4 ■
Table 7. DeviceNet Object Class Attributes
Table 8. DeviceNet Object Instance Attributes
* NOTE: These parameters are only present on the SD6L-XXXA-DSXX.
0Attribute # Access Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
1 Get/Set* MACID USINT Node Address Range 0 - 63
2 Get/Set* Baud Rate USINT Baud Rate (0) 500k Baud (default for
DS)
(1) 250k Baud
(2) 125k Baud (default for
DN)
3 Get BSI BOOLEAN Bus off Interupt Always zero
4 Get Bus-Off Counter USINT Number of times CAN went
tothe bus-off state Range 0 - 255
5 Get Allocation
Information
Allocation Choice
Byte
Master’s MAC ID
STRUCT
of:
BYTE
USINT
See DeviceNet specification
MAC ID of Master
(from Allocate) Range 0..63, 255
Modified via Allocate only
6 * Get MAC ID Switch
Changed BOOLEAN The node address switches
have changed since last
power-up or reset. (0) - No change
(1) - Changed
7 * Get Baud Rate Switch
Changed BOOLEAN The baud rate switches have
changed since last power-up
or reset. (0) - No change
(1) - Changed
8 * Get MAC ID Switch Value USINT Actual value of node address
switch setting. 0 - 99
9 * Get Baud Rate Switch
Value USINT Actual value of baud rate
switch setting. 0 - 9
Attribute # Access
Rule Name DeviceNet Data
Type Description of
Attribute Semantics of Values
1 Get Revision UINT Revision of this object The revision level of this
object. This is now at 2.
