Watlow Series SD6 Limit With Devicenet - Manual (Page 12)

Wa t l o w S e r i e s S D 6 L i m i t w i t h D e v i c e N e t ■ 1 2 ■
Table 22. Setup Object Class Attributes
Table 23. Setup Object Instance Attributes
Attribute # Access
Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
100 Get/Set Sensor Type USINT Analog input sensor type (0) Thermocouple
(default)
(1) RTD
(2) MA
(3) VOLT
(5) mV
101 Get/Set Thermocouple Linearization USINT Thermocouple Type (0) J (default for DN)
(1) K (default for DS)
(2) T
(3) E
(4) N
(5) C
(6) D
(7) PTII
(8) R
(9) S
(10) B
102 Get/Set Temperature Units BOOLEAN Temperature Units (0) °F (default for DN)
(1) °C (default for DS)
103 Get/Set Temperature Decimal
Places BOOLEAN Thermocouple/RTD precision (0) 0 (default)
(1) 0.0
104 Get/Set Process Decimal Places USINT Process precision (0) 0 (default)
(1) 0.0
(2) 0.00
(3) 0.000
105 Get/Set InfoSense TM BOOLEAN Enables the sensor feature,
which synchronizes the con-
troller with a Watlow sensor (0) NO (default)
(1) YES
106 Get/Set InfoSense TM 1 INT Set sensor point 1 code 0 to 999
(default is 500)
107 Get/Set InfoSense TM 2 INT Set sensor point 2 code 0 to 999
(default is 500)
108 Get/Set InfoSense TM 3 INT Set sensor point 3 code 0 to 999
(default is 500)
Attribute # Access Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
1 Get Revision UINT Revision of this object The revision level of this
object (currently 1)
2 Get Max Instance UINT Max allowed Instances of this
object 1 for this Class
