Wa t l o w S e r i e s S D 6 L i m i t w i t h D e v i c e N e t ■ 1 3 ■
Attribute # Access Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
109 Get/Set InfoSense TM 4 INT Set sensor point 4 code 0 to 999
(default is 500)
110 Get/Set Process Scale Low mA DINT Set the low scale for process
input 1.00 to 20.00 mA
(* 1000) (when Sensor
Type set to mA, default =
4.00 mA)
111 Get/Set Process Scale Low Volts DINT Set the low scale for process
input 0.50 to 10.00 V
(* 1000)
(when Sensor Type set to
Volt, default = 1.00 V)
112 Get/Set Process Scale High mA DINT Set the high scale for process
input 1.00 to 20.00 mA
(* 1000) (when Sensor
Type set to mA, default =
20.00 mA)
113 Get/Set Process Scale High Volts DINT Set the high scale for process
input 0.50 to 10.00 V
(* 1000)
(when Sensor Type set to
Volt, default = 5.00 V)
114 Get/Set Units Scale Low DINT Set the low range for process
input units -1999 to 9999 (* 1000)
(default = -1999)
115 Get/Set Units Scale High DINT Set the high range for
process input units -1999 to 9999 (* 1000)
(default = 9999)
116 Get/Set Set Point Low Limit
Thermocouple DINT Set the low range for the set
point Minimum operating range
(of sensor) to Set Point
High Limit – 0.001 (if
Sensor Type =
Thermocouple, default =
min. for default sensor
(* 1000)
117 Get/Set Set Point Low Limit RTD DINT Set the low range for the set
point -328 to Set Point High
Limit – 0.001 (if Sensor
Type = RTD, default = -
328)
(* 1000)
118 Get/Set Set Point Low Limit mA
and volts DINT Set the low range for the set
point -1999 to Set Point High
Limit – 0.001 (if Sensor
Type = V or mA, default =
-1999)
(* 1000)
119 Get/Set Set Point High Limit
Thermocouple DINT Set the high range for the
set point Set point low limit to max
operating range of sensor,
if Input Type =
Thermocouple (default =
max operating range for
K-Thermocouple) (* 1000)
120 Get/Set Set Point High Limit RTD DINT Set the high range for the
set point Set Point Low Limit +
0.001 to 1472, if Input
Type = RTD (default =
1472) (* 1000)
