Wa t l o w S e r i e s S D 6 L i m i t w i t h D e v i c e N e t ■ 1 0 ■
Table 17. S-Device Supervisor Object Instance Attributes
Class Services: NONE
Instance Services:
• 0x0E GET ATTRIBUTE SINGLE
• 0x10 SET ATTRIBUTE SINGLE
• 0x05 RESET SERVICE
Home Object
Class Code: 64hex
The Home Object provides access to parameters used for
the default display of the Series SD6L Home Page.
Table 18. Home Object Revision History
Revision Description
01 Initial Release
Attribute # Access Rule Name DeviceNet Data
Type Description of
Attribute Semantics of Values
3 Get Device Type SHORT_
STRING ASCII text describ-
ing the device
4 Get SEMI Standard
Revision Level SHORT_
STRING Revision level of
the SEMI S/A net-
work standard to
which the device
complies E54-0997
5 Get Manufacturer's
Name SHORT_
STRING ASCII text Watlow
6 Get Manufacturer's
Model Number SHORT_
STRING Device model num-
ber
7 Get Software
Revision Level SHORT_
STRING ASCII text of cur-
rent software revi-
sion See your specific
SD
8 Get Hardware
Revision Level SHORT_
STRING ASCII text of cur-
rent hardware
revision See your specific
SD
9 Get Manufacturer's
Serial Number SHORT_
STRING ASCII text of serial
number See your specific
SD
10 Get Device
Configuration SHORT_
STRING ASCII text of addi-
tional device DeviceNet Limit
11 Get Device Status USINT Current statua of
the device Always returns
zero
12 Get Exception
Status BYTE Current statua of
the device Always returns
zero
15 Get Alarm Enable BOOLEAN Enables setting of
exception bits for
alarms (0) - Disabled
(1) - Enabled
16 Set Warning Enable BOOLEAN Enables setting of
exception bits for
warnings (0) - Disabled
(1) - Enabled
