Wa t l o w S e r i e s S D 6 L i m i t w i t h D e v i c e N e t ■ 1 1 ■
Table 19. Home Object Class Attributes
Table 20. Home Object Instance Attributes
Class Services:
• 0x0E GET ATTRIBUTE SINGLE
Instance Services:
• 0x0E GET ATTRIBUTE SINGLE
• 0x10 SET ATTRIBUTE SINGLE
Setup Object
Class Code: 65hex
The Setup Object provides access to parameters that define
controller functions. These are the parameters found
through the front panel on the Setup Page.
Table 21. Setup Object Revision History
Revision Description
01 Initial Release
Attribute # Access
Rule Name DeviceNet
Data Type Description of Attribute Semantics of
Values
100 Get Process Value DINT Current process value -1999.999 to
9999.999
101 Get/Set Limit 1 High Set
Point DINT High Limit set point for Output 1 Range is from set
point low limit to set
point high limit
Default 75 (*1000)
102 Get Filtered Process
Value DINT Filtered process value -1999.999 to
9999.999
(* 1000), C or units
104 Get Limit Low 1 Status BOOLEAN Low limit at output 1 (0) None
(1) Limit
105 Get Limit High 1 Status BOOLEAN High limit at output 1 (0) None
(1) Limit
106 Get Input Error INT There is an analog input error (0) No error
(10001) Sensor
under range error
(10002) Sensor over
range error
107 Get Limit / alarm Low 2
Status BOOLEAN Low limit at output 2 (0) None
(1) Limit/alarm
108 Get Limit / alarm High 2
Status BOOLEAN High limit at output 2 (0) None
(1) Limit/alarm
Attribute # Access
Rule Name DeviceNet Data
Type Description of
Attribute Semantics of Values
1 Get Revision UINT Revision of this object The revision level of
this object (currently 1)
2 Get Max Instance UINT Max allowed
Instances of this
object Always 1 for this Class
