Table 26. Operational Object Instance Attributes
Class Services:
• 0x0E GET ATTRIBUTE SINGLE
Instance Services:
• 0x0E GET ATTRIBUTE SINGLE
• 0x10 SET ATTRIBUTE SINGLE
Factory/Calibration Object
Class Code: 67hex
Factory/Calibration Object
The Factory/Calibration Object provides access to parame-
ters that contain diagnostics information, calibration and
restore-parameter functions.
Table 27. Factory/Calibration Revision History
Revision Description
01 Initial Release
Attribute # Access
Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
100 Get/Set Calibration Offset DINT Offset the input reading. -999 to 999 (X 1000)
(default = 0)
132 Get/Set Limit 1 Low DINT Low limit / alarm set point for
output 1 Range is from set point
low limit to set point high
limit
Default 74 (*1000)
133 Get/Set Limit 1 High DINT High limit / alarm set point
for output 1 Range is from set point
low limit to set point high
limit
Default 75 (*1000)
134 Get/Set Limit / alarm 2 Low DINT Low limit / alarm set point for
output 2 Limit:
Range is from set point
low limit to set point high
limit
Default 74 (*1000)
Alarm:
Range of sensor if
Sensor Type is set to TC
or RTD
(default = 74.000)
-1999 to 9999 (x1000) if
Sensor Type is set to
mA or Volt.
(default = 74.000)
135 Get/Set Limit / alarm 2 High DINT High limit / alarm set point
for output 2 Limit:
Range is from set point
low limit to set point high
limit
Default 75.000
Alarm:
Range of sensor if
Sensor Type is set to
mA or Volt.
(default = 75.000)
