Wa t l o w S e r i e s S D 6 L i m i t w i t h D e v i c e N e t ■ 2 0 ■
Table 31. Programmable Class Attributes
Table 29. Programmable Object Instance Attributes
Attribute # Access Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
100 Get/set P1 USINT Programmable Parameter
Location 1 L1.Lo
101 Get/set P2 USINT Programmable Parameter
Location 2 L1.Hi
102 Get/Set P3 USINT Programmable Parameter
Location 3 L2.Lo
103 Get/Set P4 USINT Programmable Parameter
Location 4 L2.Hi
104 Get/Set P5 USINT Programmable Parameter
Location 5 A2.Lo
105 Get/Set P6 USINT Programmable Parameter
Location 6 A2.Hi
106 Get/set P7 USINT Programmable Parameter
Location 7 Addr
107 Get/set P8 USINT Programmable Parameter
Location 8 bAud
Attribute # Access
Rule Name DeviceNet
Data Type Description of Attribute Semantics of Values
1 Get Revision UINT Revision of this object The revision level of this
object (currently 1)
2 Get Max Instance UINT Max allowed Instances of this
object Always 1 for this Class
Class Services:
• 0x0E GET ATTRIBUTE SINGLE
Instance Services:
• 0x0E GET ATTRIBUTE SINGLE
• 0x10 SET ATTRIBUTE SINGLE
Programmable Object
Class Code: 68hex
Programmable Object
The Programmable Object determines what parameters
appear on the Operations Page.
Table 30. Programmable Object Revision History
Revision Description
01 Initial Release
